GNSS Front End Module (FEM)

GPS/ GLONASS/ BeiDou/ Galileo/ NavIC Front End Module 1.176GHz-1.227GHz, 1.57GHz and 2.492GHz

Cellular and Non-cellular GNSS applications
(GPS, Galileo, BeiDou, GLONASS and NaVIC)

More Info

Low Power RFIC for GNSS

CMOS dual band Receiver for L and S band
NaVIC L5 and S band
GPS L1, L2 and L5 bands
Galileo, Glonass, Beidou and QZSS support

IP offering in 0.18 and 0.13 technology nodes

More Info

Dual band dual LNA with Tx/Rx switch for TDD , 1-6 GHz, Front End Module

Dual channel with 2 stage GaAs Low Noise Amplifier (LNA) and high power silicon single-pole, double-throw (SPDT)
Low Noise Figure, Insertion Loss and Supply current
High gain, linearity and isolation

More Info

Reflective low Insertion loss high linearity SPDT for 5G TX/Rx Switch

High off isolation: 45 dB @ 1 GHz
Low insertion loss: 0.3 dB dc to 1 GHz
Operating frequencies : dc to 6 GHz
Small LGA Package : 0.6mmx0.6mm

More Info

Ka Band components for LEO Satellites Payload

Ka band downlink GaN power amplifier
Multistage designs
Low Noise LNA for Ka Band
Small package 4mm x 4mm

More Info

Very Large-Scale Innovation

Research & Intellectual Property Development.

Together We Do Much

Intelligent Team To Win Global Championships.

Silizium Circuits is an Analog Radio Frequency Intellectual Property focused R&D venture catering to the evolving requirements of the semiconductor industry globally. IP Development, Chip Design, System Design, Product Design and Human Capital Development are our core competences.

Latest Updates

News

September 14, 2021

We were one among top 8 in NXP All India challenge

Silizium Circuits is one among the eight NXP FabCI 2021Cohort Qualifiers! A 2-year Incubation & Acceleration Program with multiple associated benefits. The initiative jointly…

News

September 14, 2021

Prof. Priyadarsan Patra on board

Dr Priyadarsan Patra earlier served as a Chief Architect and Principal Scientist at the R&D divisions of Intel Corp (USA) and as the Dean…

What We Do

IP Development

We specialize in Research, Design, and Development of Analog, RF, and mixed-signal Silicon IP to customers for wireless, wirelines, and interface domains.

Product Design

End-to-end product development through technology selection from architecture, circuit and physical design ultimately to a packaged finished chip or module.

System Design

Designing and developing the hardware and software for wireless IPs and RF Front-end systems, we have it all covered.

Join Us

Are you a student willing to learn and further develop your skills in the microelectronics domain? Are you a new graduate who desires to experiment and gain experience in areas of circuit design or R&D. Then get ready to join us!
